The Everet PTZ camera NDI lineup—encompassing the Everet EVP312 Auto Tracking NDI|HX2 PTZ Camera with 12x Optical Zoom, Everet EVP320 Auto Tracking NDI|HX2 PTZ Camera with 20x Optical Zoom, Everet EVX220 NDI®|HX3 Auto Tracking PTZ Camera 20x zoom, Everet EVX230 NDI®|HX3 Auto Tracking PTZ Camera 30x zoom, Everet EVPRO1 4K60 NDI PTZ Camera with 12x Zoom and Auto Tracking, and Everet EVPRO2 4K60 NDI PTZ Camera with 30x Zoom and Auto Tracking—delivers automated pan-tilt-zoom video capture designed for installation in hybrid meeting rooms, lecture halls, places of worship, legislative chambers, and production studios. Every model in this series integrates IP-based network control and video transmission through NDI|HX2 or NDI|HX3 streaming standards, while also supporting RTSP, RTMP, SRT, and NDI bridge functionality for broad video routing flexibility. Production connectivity is established via concurrent physical video output connections, featuring 3G-SDI, HDMI, IP, and USB interfaces on every model. Systems integrators and operators benefit from streamlined power and infrastructure management using Power over Ethernet (PoE), hardware tally visual indicators, and native compatibility with software systems including Iris enabled software control for remote camera operation.

Selecting the appropriate model depends on required resolution, optical magnification, and IP streaming protocol standards. The FHD range includes the Everet EVP312 (12x optical zoom) and Everet EVP320 (20x optical zoom), both operating over NDI|HX2 protocols for efficient bandwidth handling across local area networks. For IP performance in FHD, the Everet EVX220 (20x optical zoom) and Everet EVX230 (30x optical zoom) deliver NDI®|HX3 video streams. Production environments demanding maximum clarity utilize the 4K UHD series, featuring the Everet EVPRO1 with 12x optical zoom and wide angle capabilities, alongside the flagship Everet EVPRO2 with 30x optical zoom; both 4K UHD models support both NDI|HX2 and NDI|HX3 protocols. All six models feature built-in hardware auto tracking, enabling automatic subject framing without dedicated camera operators, and are manufactured in both black and white color options (including model codes EVP312/EVP312W, EVP320/EVP320W, EVX220/EVX220W, EVPRO1/EVPRO1W, and EVPRO2/EVPRO2W) to match room environments.

In a hybrid meeting room deployment, an automated camera setup must capture speakers at the head table as well as participants across larger seating areas without manual intervention. Utilizing the Everet EVP320 or Everet EVX220 with 20x optical zoom, or the Everet EVPRO1 with 12x optical zoom and wide angle coverage, the integrated hardware auto tracking function automatically detects and frames active presenters moving across the front of the room. The operator monitors the feed via IP streaming protocols over NDI while supplying video directly to local displays via HDMI and USB outputs simultaneously, receiving visual tally operational status right on the camera unit while running power over a single PoE network cable.

Key features

• NDI|HX2 and NDI®|HX3 Protocol Support — Provides efficient high-definition and 4K UHD network video distribution using NDI|HX2 (EVP312, EVP320, EVPRO1, EVPRO2) and NDI®|HX3 (EVX220, EVX230, EVPRO1, EVPRO2) protocols alongside RTSP, RTMP, SRT, and NDI bridge formats.
• Comprehensive Video Interface Selection — Equipped with simultaneous 3G-SDI, HDMI, IP, and USB video connectivity across all models for flexible hardware switcher and software platform routing.
• Hardware Auto Tracking Integration — Features built-in auto tracking functionality across the entire model line to automatically follow moving subjects without continuous manual operator adjustments.
• 4K UHD and FHD Sensor Resolution Options — Delivers FHD image quality on EVP312, EVP320, EVX220, and EVX230 models, and 4K UHD resolution on EVPRO1 and EVPRO2 models.
• Optical Zoom Options Up to 30x — Offers focal flexibility ranging from 12x optical zoom (EVP312, EVPRO1) and 20x optical zoom (EVP320, EVX220) up to 30x optical zoom (EVX230, EVPRO2) for short to long-throw installations.
• Wide Angle Optics Option — The Everet EVPRO1 incorporates wide angle optical design alongside 12x optical zoom to cover wide rooms from short throw distances.
• Power over Ethernet (PoE) Support — Simplifies physical installation by delivering DC power, IP control, and multi-protocol IP video over a single network cable connection.
• Iris Software Integration — Native support for Iris enabled control systems allows unified remote management over local networks.
• Integrated Hardware Tally Indicators — Built-in visual tally light informs present studio talent or presenters when the camera feed is actively selected on air.
• Dual Housing Color Options — Available in both black and white finishes across models (EVP312/EVP312W, EVP320/EVP320W, EVX220/EVX220W, EVPRO1/EVPRO1W, EVPRO2/EVPRO2W) for discreet surface mounting.

Model Comparison and Technical Specifications

The Everet NDI PTZ lineup comprises six models tailored to specific resolution requirements, optical zoom distances, and network protocol capabilities.

• Everet EVP312 Auto Tracking NDI|HX2 PTZ Camera with 12x Optical Zoom — Features FHD resolution, 12x optical zoom, NDI|HX2, SRT, RTSP, RTMP, and NDI bridge streaming over 3G-SDI, HDMI, USB, and IP, with PoE and tally options in black or white chassis.
• Everet EVP320 Auto Tracking NDI|HX2 PTZ Camera with 20x Optical Zoom — Delivers FHD video quality with a 20x optical zoom lens, supporting NDI|HX2, SRT, RTSP, RTMP, and NDI bridge across 3G-SDI, HDMI, IP, and USB outputs in black or white chassis.
• Everet EVX220 NDI®|HX3 Auto Tracking PTZ Camera 20x zoom — Provides FHD video with 20x optical zoom, NDI®|HX3 streaming alongside SRT, RTSP, RTMP, and NDI bridge protocols over 3G-SDI, HDMI, USB, and IP outputs in black or white chassis.
• Everet EVX230 NDI®|HX3 Auto Tracking PTZ Camera 30x zoom — Incorporates a 30x optical zoom lens for long-throw distances, delivering FHD resolution over NDI®|HX3, SRT, RTSP, RTMP, and NDI bridge streaming with simultaneous 3G-SDI, HDMI, USB, and IP connectivity in black or white chassis.
• Everet EVPRO1 4K60 NDI PTZ Camera with 12x Zoom and Auto Tracking — Captures 4K UHD video quality with a 12x optical zoom lens, wide angle support, and dual NDI|HX2 and NDI®|HX3 streaming capabilities alongside 3G-SDI, HDMI, IP, and USB interfaces in black or white chassis.
• Everet EVPRO2 4K60 NDI PTZ Camera with 30x Zoom and Auto Tracking — Features 4K UHD resolution combined with a 30x optical zoom lens for long-range coverage, supporting both NDI|HX2 and NDI®|HX3 protocols over simultaneous 3G-SDI, HDMI, IP, and USB connections in black or white chassis.

For Integrators and Resellers

System design and network planning require matching physical video infrastructure, IP streaming protocols, and control standards to exact facility specifications. The Everet PTZ camera range standardizes Power over Ethernet (PoE) capability, integrated Tally indicators, and simultaneous video output interfaces—including 3G-SDI, HDMI, USB, and IP streaming—across all models. System integrators deploying hybrid architectures can output baseband video locally over SDI or HDMI while routing control, Tally signals, and IP streams over a single Ethernet connection. Additionally, all models support automated tracking workflows and feature compatibility with Iris system controls for software-driven management within automated production environments.

Model Selection and System Integration

For standard Full HD infrastructure requiring NDI|HX2, RTMP, RTSP, SRT, and NDI bridge protocol support, the Everet EVP312 Auto Tracking NDI|HX2 PTZ Camera with 12x Optical Zoom provides short-to-medium range coverage, while the Everet EVP320 Auto Tracking NDI|HX2 PTZ Camera with 20x Optical Zoom supplies extended optics for larger room depths. Networks configured for NDI|HX3 streaming alongside SRT, RTSP, RTMP, and NDI bridge protocols can integrate the Everet EVX220 NDI®|HX3 Auto Tracking PTZ Camera 20x zoom for medium-throw positioning, or the Everet EVX230 NDI®|HX3 Auto Tracking PTZ Camera 30x zoom when long-distance reach is required in FHD image quality.

Installations designed around 4K UHD resolution standards utilize the Everet EVPRO1 4K60 NDI PTZ Camera with 12x Zoom and Auto Tracking, which incorporates wide-angle optics alongside dual NDI|HX2 and NDI|HX3 streaming modes. For high-resolution requirements across large spaces, the Everet EVPRO2 4K60 NDI PTZ Camera with 30x Zoom and Auto Tracking combines 4K UHD imaging with 30x optical zoom and complete protocol flexibility. Each model in the series is available in black and white color options to accommodate structural and aesthetic specifications across permanently installed environments.

The Everet NDI PTZ camera series provides automated subject tracking, IP streaming, and simultaneous video output for corporate meeting rooms, education facilities, houses of worship, and live broadcast environments. Controlled via NDI|HX, RTSP, or SRT, these cameras deliver video feeds over 3G-SDI, HDMI, IP, and USB simultaneously while receiving power over Power over Ethernet (PoE).

In a hybrid conference room or lecture hall setting, presenting speakers moving across a stage present positioning challenges for single static cameras. An Everet auto-tracking NDI PTZ camera detects and follows the presenter across the room, providing PTZ movement so operators do not need manual joystick intervention during live presentations.

Key features

• NDI|HX Protocol Integration — Enables IP streaming across standard local area networks using NDI|HX2 or NDI®|HX3 alongside SRT, RTSP, RTMP, and NDI bridge protocols.
• Simultaneous Multi-Interface Output — Transmits video signals concurrently over 3G-SDI, HDMI, USB, and IP streaming interfaces for routing and recording workflows.
• Auto Tracking Functionality — Tracks moving subjects within the coverage area automatically without requiring manual camera positioning.
• Iris Support — Integrates with iris platform controls for software-based camera management and production workflows.
• Optical Zoom Options — Offers selectable 12x, 20x, and 30x optical zoom lenses to match shallow or deep installation distances.
• 4K UHD and FHD Resolution Options — Delivers 4K UHD resolution on EVPRO series models or Full HD video output across EVP and EVX model ranges.
• Power over Ethernet (PoE) — Carries video, control, tally signals, and power over a single network cable to simplify infrastructure setup.
• Integrated Tally Lights — Displays live broadcast status indicators to present speakers and camera operators.

NDI Protocol Standards Across Everet PTZ Models

Everet NDI PTZ cameras are network-integrated pan-tilt-zoom camera systems designed for installation in churches, hybrid meeting spaces, lecture halls, and broadcast studios. The product range covers six specific model configurations engineered to deliver video streams across local network infrastructure while providing physical connection outputs via 3G-SDI, HDMI, IP, and USB interfaces. System operators and integrators utilize these devices to stream video, relay tally signals, and transmit PTZ command data over standard Ethernet cables.

Protocol Variations and Network Streaming Modes

The NDI standard implemented in each camera determines the streaming profile and network transmission method. The standard FHD product line includes the Everet EVP312 Auto Tracking NDI|HX2 PTZ Camera with 12x Optical Zoom and the Everet EVP320 Auto Tracking NDI|HX2 PTZ Camera with 20x Optical Zoom, both configured with NDI|HX2, RTMP, RTSP, SRT, and NDI bridge protocols. For installations requiring NDI|HX3 performance, the Everet EVX220 NDI®|HX3 Auto Tracking PTZ Camera 20x zoom and the Everet EVX230 NDI®|HX3 Auto Tracking PTZ Camera 30x zoom incorporate NDI|HX3 alongside RTMP, RTSP, SRT, and NDI bridge streaming options.

The high-resolution tier comprises the Everet EVPRO1 4K60 NDI PTZ Camera with 12x Zoom and Auto Tracking and the Everet EVPRO2 4K60 NDI PTZ Camera with 30x Zoom and Auto Tracking. These 4K UHD models support dual NDI capabilities—supporting both NDI|HX2 and NDI|HX3 formats within the same hardware framework—along with RTMP, RTSP, SRT, and NDI bridge protocols. Additionally, the EVPRO1 includes a wide angle option, while all six camera models provide Power over Ethernet (PoE), integrated hardware tally lights, and full operational support for Iris (https://www.tryiris.ai/iris-enabled) integration to facilitate software-based control across network deployments.

Comparing Optical Zoom Ranges: 12x, 20x, and 30x Optics

Selecting the appropriate optical zoom level depends directly on the physical distance between the camera mounting position and the subject, as well as the required field of view. The Everet NDI PTZ camera lineup is structured around three distinct optical magnification options: 12x, 20x, and 30x zoom optics. Each lens system maintains native optical image quality, delivering video streams over 3G-SDI, HDMI, IP, and USB interfaces. Alongside standard network protocols, all six camera models in this range include support for Iris software control and platform management.

12x Optical Zoom Models

The 12x optical zoom configuration is engineered for short to medium throw distances. Within this category, the Everet EVP312 Auto Tracking NDI|HX2 PTZ Camera with 12x Optical Zoom provides Full HD (FHD) video output with NDI|HX2 IP streaming, making it suitable for smaller rooms and close-range capture. For environments requiring higher resolution and wider framing, the Everet EVPRO1 4K60 NDI PTZ Camera with 12x Zoom and Auto Tracking delivers 4K UHD image quality, includes a wide-angle optic option, and supports both NDI|HX2 and NDI|HX3 IP streaming along with POE, Tally, and Iris support.

20x and 30x Optical Zoom Models

For medium to long throw distances, 20x optical zoom optics offer extended focal reach while preserving wide-angle coverage when unzoomed. The Everet EVP320 Auto Tracking NDI|HX2 PTZ Camera with 20x Optical Zoom provides FHD video streaming via NDI|HX2, RTMP, RTSP, and SRT. The Everet EVX220 NDI®|HX3 Auto Tracking PTZ Camera 20x zoom utilizes NDI|HX3 streaming for FHD transmission.

When maximum magnification is required across large halls or auditoriums, 30x optical zoom optics allow tight framing from long distances. The Everet EVX230 NDI®|HX3 Auto Tracking PTZ Camera 30x zoom offers FHD resolution over NDI|HX3 with full auto-tracking functionality. The Everet EVPRO2 4K60 NDI PTZ Camera with 30x Zoom and Auto Tracking combines 30x optical zoom optics with 4K UHD image capture, featuring dual NDI|HX2 and NDI|HX3 streaming options, NDI bridge support, POE, Tally, and Iris platform integration.

Video Output Interfaces: 3G-SDI, HDMI, IP, and USB Integration

Every camera in the lineup—specifically the Everet EVP312 Auto Tracking NDI|HX2 PTZ Camera with 12x Optical Zoom, Everet EVP320 Auto Tracking NDI|HX2 PTZ Camera with 20x Optical Zoom, Everet EVX220 NDI®|HX3 Auto Tracking PTZ Camera 20x zoom, Everet EVX230 NDI®|HX3 Auto Tracking PTZ Camera 30x zoom, Everet EVPRO1 4K60 NDI PTZ Camera with 12x Zoom and Auto Tracking, and Everet EVPRO2 4K60 NDI PTZ Camera with 30x Zoom and Auto Tracking—is built with a multi-interface hardware architecture containing 3G-SDI, HDMI, IP, and USB video connectivity. This hardware configuration permits concurrent signal delivery across physical baseband infrastructure, local networks, and direct host devices without requiring external conversion hardware.

Baseband Video Outputs: 3G-SDI and HDMI

The 3G-SDI connection supplies a standardized video signal designed for distribution directly into hardware switchers, matrix routers, and dedicated capture hardware. Parallel to SDI, the HDMI interface provides a direct video output intended for local confidence monitoring, in-room displays, or secondary hardware encoding systems. On Full HD units such as the EVP312, EVP320, EVX220, and EVX230, these baseband connections output high-definition resolution, whereas the 4K UHD EVPRO1 and EVPRO2 support ultra-high-definition video output capabilities across their baseband hardware connections.

Network and Host Interface Options: IP, USB, and Control Compatibility

The IP streaming architecture supports standard network protocols including RTSP, RTMP, SRT, and NDI bridge alongside integrated NDI|HX protocols. Power over Ethernet (PoE) functionality consolidates power delivery, IP video streaming, and control data into a single network cable connection. The USB video interface operates for direct ingestion into host computers. Furthermore, the camera series features IRIS integration support (https://www.tryiris.ai/iris-enabled) for software ecosystem control, while onboard Tally functionality provides visual status indication for operators during active broadcasts.

Resolution Capabilities: FHD and 4K UHD Performance Specs

Image resolution directly influences visual fidelity, bandwidth allocation, and downstream display compatibility across professional AV installations. The Everet NDI camera lineup provides options in both Full HD (FHD) and 4K Ultra High Definition (4K UHD) performance tiers. Selecting the appropriate resolution standard depends on broadcast parameters, display screen sizes, and system encoding capabilities within the production infrastructure.

Full HD Processing and Deployment

The Full HD models within the range offer reliable 1080 resolution, balancing clear visual detail with network transmission rates. The Everet EVP312 Auto Tracking NDI|HX2 PTZ Camera with 12x Optical Zoom and the Everet EVP320 Auto Tracking NDI|HX2 PTZ Camera with 20x Optical Zoom utilize FHD sensor processing tailored for IP network streaming over NDI|HX2. Similarly, the Everet EVX220 NDI®|HX3 Auto Tracking PTZ Camera 20x zoom and the Everet EVX230 NDI®|HX3 Auto Tracking PTZ Camera 30x zoom process video in FHD while leveraging NDI|HX3 protocol capabilities. These models deliver stable image output across 3G-SDI, HDMI, IP, and USB interfaces, making them suitable for standard streaming setups, lecture capture, and remote meeting systems.

4K UHD Optics and Advanced Control Integration

For installations demanding maximum image clarity and video production, the 4K UHD models provide four times the pixel count of standard FHD video pipelines. The Everet EVPRO1 4K60 NDI PTZ Camera with 12x Zoom and Auto Tracking features 4K UHD processing alongside a wide angle optical design. The Everet EVPRO2 4K60 NDI PTZ Camera with 30x Zoom and Auto Tracking combines 4K UHD resolution with extended 30x optical zoom capabilities. Both 4K models output native high-resolution signals across 3G-SDI, HDMI, IP, and USB interfaces, supporting high-density displays, auto tracking capabilities, and crop zones in live switching environments.

To ensure operational management across both resolution tiers, all six Everet PTZ cameras incorporate Iris software integration (https://www.tryiris.ai/iris-enabled). This enables system operators to remotely configure image adjustments, exposure parameters, and PTZ functions across FHD and 4K UHD models within a unified control framework.

Auto Tracking and Iris Support for Automated Workflows

Integrated auto tracking across the Everet PTZ lineup automates presenter framing without requiring constant manual control from a dedicated operator. The entry FHD models, including the Everet EVP312 Auto Tracking NDI|HX2 PTZ Camera with 12x Optical Zoom and the Everet EVP320 Auto Tracking NDI|HX2 PTZ Camera with 20x Optical Zoom, leverage pan-tilt-zoom motion mechanisms to maintain subject lock across standard IP network installations. In network architectures, the Everet EVX220 NDI®|HX3 Auto Tracking PTZ Camera 20x zoom and the Everet EVX230 NDI®|HX3 Auto Tracking PTZ Camera 30x zoom deliver automated subject follow paired with NDI|HX3 video output. For high-resolution productions, the Everet EVPRO1 4K60 NDI PTZ Camera with 12x Zoom and Auto Tracking and the Everet EVPRO2 4K60 NDI PTZ Camera with 30x Zoom and Auto Tracking perform automated subject tracking at 4K resolution, preserving image details during pan and tilt adjustments.

Iris Platform Compatibility and IP Control Integration

To extend automation capabilities across complex multi-camera environments, Everet PTZ cameras provide support for Iris enabled software systems. Integrating Iris allows network administrators and systems integrators to implement presenter switching and remote camera control across local networks. When combined with onboard PoE power delivery, Tally state synchronization, and IP control standards, Iris software enables coordination between hardware tracking mechanics and external video switchers. This integrated software approach simplifies camera management in corporate boardrooms, lecture halls, and worship environments by eliminating the need for standalone physical tracking hardware or dedicated camera operators.

Power over Ethernet and Tally Functionality in Live Production

Deploying PTZ cameras in multi-camera live production environments requires streamlined cabling and clear visual signaling for talent and operators. Power over Ethernet (PoE) and built-in tally functionality are hardware features integrated across the entire Everet NDI camera lineup. By supplying power over the standard network connection alongside IP video streaming (NDI|HX2, NDI|HX3, RTSP, SRT), PoE eliminates the need for localized AC power outlets near each camera mounting location.

Single-Cable Deployment across the Everet PTZ Lineup

The inclusion of PoE simplifies hardware setup across diverse installation sites, such as council chambers, houses of worship, lecture halls, and broadcast studios. Every camera in the range—including the Everet EVP312 Auto Tracking NDI|HX2 PTZ Camera with 12x Optical Zoom, Everet EVP320 Auto Tracking NDI|HX2 PTZ Camera with 20x Optical Zoom, Everet EVX220 NDI®|HX3 Auto Tracking PTZ Camera 20x zoom, Everet EVX230 NDI®|HX3 Auto Tracking PTZ Camera 30x zoom, Everet EVPRO1 4K60 NDI PTZ Camera with 12x Zoom and Auto Tracking, and Everet EVPRO2 4K60 NDI PTZ Camera with 30x Zoom and Auto Tracking—supports PoE operation. Network switches supplying PoE standard power allow video data, camera management, auto-tracking telemetry, and operational power to traverse a single Ethernet cable.

Tally Light Indicators and Software Integration

Live switching requires real-time feedback regarding which camera feed is active on air or queued in preview. The integrated tally indicators on Everet PTZ cameras receive status flags directly over the IP network via NDI protocol commands or hardware tally triggers. When integrated into software controllers or automated systems such as Iris, the tally indicator changes state dynamically to inform presenters and production crew of the active broadcast source. All six models—from the FHD EVP and EVX series to the 4K UHD EVPRO models—include this hardware tally support to ensure synchronized visual feedback during live studio or remote events.

Frequently asked questions

Which Everet PTZ camera NDI models support NDI|HX3?

The Everet EVX220 NDI®|HX3 Auto Tracking PTZ Camera 20x zoom, Everet EVX230 NDI®|HX3 Auto Tracking PTZ Camera 30x zoom, Everet EVPRO1 4K60 NDI PTZ Camera with 12x Zoom and Auto Tracking, and Everet EVPRO2 4K60 NDI PTZ Camera with 30x Zoom and Auto Tracking support NDI|HX3 streaming protocols alongside RTMP, RTSP, SRT, and NDI bridge.

What optical zoom options are available in the Everet NDI PTZ lineup?

Everet provides 12x optical zoom on the EVP312 and EVPRO1 models, 20x optical zoom on the EVP320 and EVX220 models, and 30x optical zoom on the EVX230 and EVPRO2 models.

Do Everet NDI PTZ cameras support Iris software?

Yes, Everet NDI PTZ cameras feature Iris support for compatibility within Iris-enabled production environments.

What physical video interfaces are standard across Everet PTZ NDI models?

All models in the lineup include 3G-SDI, HDMI, IP, and USB video interfaces as standard physical connectivity options.
